Inverter ibrido a fase bivisa SANDISOLAR 7.2KW
Modello: SD-4872WP-US
It is a versatile 7.2kW split-phase hybrid inverter for the US market, featuring dual-channel MPPT with 16A per channel, supporto per FINO a 6 Unità in parallelo (configurable for split-phase, single-phase, or three-phase systems), and UPS-level 10ms switching time. It delivers 7200W rated output with 10800VA peak power, accepts up to 150A battery charging current, operates with or without batteries, supports diesel generator input and CT zero-export functionality, and offers intuitive touchscreen control, Diagnostica remota, and OTA updates—all while complying with UL1741 and FCC standards.
-
Key Specs & Visuals
-
-
Attrazioni
-
- Dual MPPT design improves solar efficiency with 7200W rated output and 10800VA peak power.
- Supporti fino a 6 units in parallel for flexible single-phase, split-phase, and three-phase systems.
- 10ms UPS-level switching ensures seamless backup during power outages.
- Battery-free operation and diesel generator compatibility enable flexible system design.
- Smart features include touchscreen control, remote monitoring, Aggiornamenti OTA, and CT zero export control.
- Supports 4HP motor loads and complies with UL1741 and FCC standards.
Richiedi un preventivo
Scarica la brochure
Vantaggi fondamentali
Alta Efficienza
Dual MPPT design improves solar energy utilization.
Alta potenza
7200W rated and 10800VA peak capacity.
Scalabilità del sistema
Supporti fino a 6 units in parallel expansion.
Commutazione veloce
10ms UPS-level seamless transfer.
Flexible Energy System
Works with or without battery storage.
Affidabilità Certificata
Conformi agli standard UL1741 e FCC.
Specifiche del prodotto
Modalità AC
| Tensione di ingresso nominale | 120V (L1/N, L2/N) / 240Vac (L1/L2) | Gamma di tensione di fase in ingresso | (85Vac ~ 140Vac) ±2% |
| Frequenza | 50Hz / 60Hz (Rilevamento automatico) | Gamma di frequenze | 47±0,3Hz ~ 55±0,3Hz (50 Hz); 57±0,3Hz ~ 65±0,3Hz (60Hz) |
| Sovraccarico / Protezione dai cortocircuiti | Interruttore automatico | Efficienza | >95% |
| Tempo di conversione (Bypass & invertitore) | 10Sig. (tipico) | AC Reverse Protection | Sì |
Visualizza il documento completo
Applicazione
This 7.2KW split phase hybrid inverter is designed for residential, small commercial, and off-grid energy storage systems. Fornisce alimentazione di riserva affidabile, flexible system expansion, and intelligent energy management for solar self-consumption, zero-export grid-tied applications, and generator-hybrid power systems.
